Blower Motor – Single Shaft Motor 12V CW (1001003)

Blower Motor – Single Shaft Motor 12V CW 73R0422, HA1070, HA1700, RD5-6526-0, 3949262, 60009-5009, 6009-5003
Voltage: 12V
Rotation: CW
Speed: 1
Vent: Vented
Mount Type: Strap
Overall Length (A): 4 3/4″
Motor Length (B): 4″
Shaft Length (C): 1 5/8″
Motor Diameter (D): 3″
Stud Span (E): 2 5/16″
Shaft Diameter: 5/16″

Applications:
MACK Blower Motor WL, WS Series (1986-1981); Conventional (1985-1981)

Peterbilt Blower Motors All Conventional Class 8 Series (1994-1988)

Volvo Blower Motor All Models

Western Star Blower Motor 48-4900,5800,5900,6900 Series (2001-1983); 4800,4900,5800,5900 Series (1998-1985)

Cross Reference: 1001003, 3034, ABP N83 301001, ABP N83901911, 203178, HA1070, HA1700, HA10700,937153, 150-4479, 102-1104, E-803136, 2809-541-024, 2809-541-117, 2809-541-164, E0TZ-19805B, 35504, 35601, 35777, 274265, 1099016, 274341, 1-9269, 208919, 208931, 209189, 117283-C91, 26-13279, 203132BSM, 2809-540-036, 73R0342, 73R0532, RD-5-6526-0, RF765B360610, PM3692, 01-2610, 30-1005, 176117, 60009-5009, 6009-5003, ABPN83301001, ABPN83901911, 117283C91, 123756, RD5-6526-0, 3949262
