The Sanden Compressor is a great choice for your truck air conditioning needs. This compressor is ideal for R134a refrigerant and has a variety of features that make it a great choice for your vehicle. The CW rotation and long key shaft make it easy to install and the diode protection ensures your compressor will last for years to come. The head type is GV and the wire type is 1 wire male packard, making it easy to connect to your existing system. This powerful compressor includes a 200cc oil charge and can be used with PAG100 oil. When you need a reliable and efficient air conditioning compressor, choose the Sanden 4434 Compressor.
Sanden Model/s #: 4434, 4447, 6078
Description: Sanden Flex FLX7 Compressor 4434 PAG E-MT 132mm 2A 12V GV HEAD
Volts: 12V
Clutch Diameter: 132mm
No. of Grooves: 2 groove
Belt Type: Two 1/2” Belts
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 200cc Oil
Oil Type: PAG100
Fitting Port Position: Horizontal
Fitting Style: Rear Universal O-ring FLX-7 Pad
Head Type: GV
Wire Type: 1 Wire Male Packard #12015791 W/ Diode & Bullet Jumper
Model: SD7H15HD
Product Name: Sanden Compressor 6078
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Diode Protection: w/diode
Compressor Family: SD7H15
Style: HD
Mount Type: Ear 8 Long
Ear ID: 83.3
Displacement: 155.00
Port Clocking: Rear
Head Port Style: O-Ring
Gauge Line to First Groove: 23.80
Gauge Line to Middle Groove: 0.00
Gauge Line to End Groove: 39.55
Replacement Clutch Assembly: 4434-9931
Schematic: CLICK HERE
Service Manual: CLICK HERE
Application: Versatile 160 / 555 / 835 / 855 / 875 / 895 / 945 / 955 / 975 / 1150 SD510 (model 9103) w/2 gr clutch
Cross References: 1101160, 5190, 5290, ABP N83 304064, 4474, ABP N83 304234, 967263, 300-5496, 300-5524, 330-1710, ZGG705181, 68170, 8530-4447, 20-14434, 75R89422, RF999994520, 4434, 4447, 512211, 512267, 03-3709, 50-5106, 1401227, 20-10018-AM, 20-14447, 20-10122, ABPN83304064, ABPN83304234, 124830, PTAC5190, PTAC5290, 87447531, 63557, 63456, 1521879, 10360581, 67170, 68170, 85304447, 5512697, 6512697, 7512697, 967263, TEM967263, 2006676, 201005024, 2014434, 2014435, 2014447, C2025, 3005524
