NEW Original Sanden Compressor 4521, 4524, 6632 (1101423)

Sanden Model/s #: 4521, 4524, 6632, 196632

Description: OEM Sanden Compressor SD5H14 132mm 24V “M” BACK HEAD HOR 1 X 14 TUBE-O 6632

Compressor Family: SD5H14
Style: HD
Mount Type: Ear 8 Long
Ear ID: 83.3
Refrigerant: R134A
Displacement: 131.00
Rotation Direction: CW
Oil Qty (cc): 175
Cylinder Head: M
Port Angle: H
Port Clocking: Rear
Head Port Style: 1X14
Rotor Size: 132
Rotor Groove: A2
Gauge Line to First Groove: 23.80
Gauge Line to Middle Groove: 0.00
Gauge Line to End Groove: 39.55
Coil Voltage: 24
Connector: 1 Wire Male Bullet

Replacement Clutch Assembly: 6514-6210

Schematic: CLICK HERE

Service Manual: CLICK HERE

Applications:
MAIT HR120 ANY Compressors

Cross Reference: 56632, 204521, 5512234, 6512234, 7512234, 5291W5204, 20-10090, C2256, 3005214, , 300-5214, 4521, 6632, 50-5570, 124766, PTAC56632
