BLOCK TYPE EXPANSION VALVE 1.5 TON 0015318, 71R8301, 329-406 (2001000)

Description: BLOCK TYPE EXPANSION VALVES 1.5 TON, #6 X #10 X #8 X #8
OEM#: 329-406; RD-5-6868-0, 1669337-C1, 04322165-4, 72162195, E1HZ-19849A, C8OZ-19835AB, 1-2467Q, 404098, D2953-5350, EA1065, EA1210, RD4157-0
Rating: 1 1/2 ton
Mount Type: Block Type
Mounting Type: Block
Product Name: Expansion Valve
Refrigerant Type: R12/R134a
Hose Inlet Size: #6
Hose Outlet Size: #10
Evaporator Inlet Size: #8
Evaporator Outlet Size: #8
Notes: O-ring style
Liquid Inlet from Cond: #6 – 3/8”
Liquid Outlet to Evap: #8 – 1/2”
Suction Inlet from Evap: #8 – 1/2”
Suction Outlet to Comp: #10 – 5/8”
Note: ABPN83-308011, S10-329-015, A22-18591-000, N83-308041, SI0329-412, 329-005, 58590P, 4379-RD5-6868-0, 4379-RD4157-0, 4300-57104, 4379-RD41570, 4379-RD568680, 7979-404098, 18-04275, BSM308011, 3916657, 540031, 040138-123, RD5-7125-0, 60012-5011, 60012-4401, 118321-C1, 60-5880-T1, 432-2165, 79840, 284238M1, 3311533M91

Applications:
Freightliner Truck Expansion Valves and Orifice Tube Business Class (1996-1994); Classic Series (1996-1981) & (1991-1974)

International(Navistar) Truck Expansion Valve (1993-1989)

Kenworth Expansion Valve Low Cab Forward (1993-1987); Cab Over Engine (2002-1982); Conventional Series (2008-1976); T270 thru T880 Series (2008-1995); W900 Series (2009-1995)

MACK Expansion Valve CH,CL Series (2012-1988), CM Series (2000-1988); CS Series (2000-1979); CX, Vision Series (2002-2000); LE,MR,MS Series (2011-1986); MS Series (1993-1979); MH Series (1993-1986); RB,RD,DM,DMM Series (2005-1988); RW Series (1995-1978)

Peterbilt Expansion Valve (1996-1976)

Volvo Expansion Valve FE Series (1994-1983); F6,F7,F86,FE,RXII,RC,RCII,WH,WX,WXLL,N,RBII,WAH,WCA,WG,WIA,VN Series (1993-1981); Xpeditor Series (2002-1988); WG,WIA,WCA Series (2000-1988); WCA, WIA Series (1996-1988); N Series (1993-1984); WCS, WCL Series (1989-1986); VN 420, 610 Series (1998-1996); Volvo/GMC/White Series (1994-1981)

Western Star Expansion Valve All Models (2015-1983); 3800 Series (1998-1988)
AGCO – Allis Expansion Valve 6260-6275, 7085, 7110, 7120, 7145, 8610-8630, 9130-9190, 9455 Series

CASE / IH – Expansion Valve 186, 786, 886, 996, 1086, 1486, 1586, 3088, 3288, 3388, 3488, 3588, 3688, 3788, 5088, 5288, 5488, 6388, 6588, 6788, 7288, 7488, 9110, 9130, 9150, 9170, 9180 Series
Caterpillar All Models Expansion Valve

DEUTZ-ALLIS CORP DX83/90/110/120/140/145/160 Series Expansion Valve
Ford-New Holland D6, 836, 846, 856, 876, 936, 946, 956, 976, 2310, 2610, 2910 Expansion Valve

Kobelco-Excavators TXV Expansion Valve
KOMATSU Excavator, PC Series; WA350 – WA600 Expansion Valve
MASSEY FERGUSON Combine 850 / 860 / 865 – Expansion Valve
MASSEY FERGUSON Tractor 3050 / 3060 / 3070 / 3090 / 3120T / 3140 / 3630 / 3650 / 3660 / 3670 / 3680 / 3690 – Expansion Valve

Versatile D6 / 756 / 836 / 856 / 876 / 1156 Block Valve
Versatile Swather w/Kysor AC (79-86) Block Valve

Cross Reference: 2001000, 1600, 1600G, 1607, ABP N83 308011, ABP N83 308051, ABP N83 308081, ABP N83 308181, ABP N83 329005, 04322165-4, 903-700, 540277, 540344, 0015318, 101-100, 210-019, 118321-C1, 605880-T1, 3V-0258, RD-4157-0, EA1060, EA1065, EA1255, EA10650, EA10750, EA10750, EA12550, EA14200, 932110, 932115, 450-6500, 520-1005, 15-5123, 432-2165, 71307202, 72162195, 04-15004, E-805025, E-805031, E-805032, 932110, 932115, 932156, 1195532, 71370202-3, ZGG11135, ZGG12467, ZGG16289, C8OZ-19849A, E1HZ-19849A, 97005763, 38878, 38901, 681-830-00-084, 681-830-00-84, 681-833-00-64, A06-81830-000, A22-18591-000, A644-030-00, BOA70 321 00 409, BOA80 321 00 063, BOA80 321 00 069, BOA80 321 00 149, RDH RD5 6868 0, SI0329-015, SI0329-412, SI0329-440, 404098, 404058, 404866, 405017, 405018, AH203871, AT261345, KV2298, 1-2467Q, PTAC1607, PTAC1600, 540031BSM, 58294P, 58590P, D2953-5350, RD-5-6868-0, 1812001, 1875001, 1875002, 1899004, 404410, 404451, 4300-57104, 4379-RD41570, 4379-RD568680, 7979-284238M1, 1-1054, 1-1135, 1-2467, 1-3586, 1-9267, 207349, 207350, 12467Q, 1280331-C1, 1669337-C1, 1676649-C1, 1676665-C91, 431606-R1, 31-30901-P, 040138-105, 040138-107, 329-404, 329-406, 18-04275, 308011BSM, 71R8300, 71R8301, 71R8340, RD-4157-0, RD-5-7125-0, RF90520431, RF9141000152, EXV-1017, EXV-1017, 61-4091, 12-0613A, 12-2012A, 12-2012G, 16-7000, 79840, 3916181, 540031, 60012-4401, BSM308011, V1111478, V1111909, V1118406, 60012-5011, 60058-3401, 040138-123, 31-30901, 31-30901-AM, 31-30905, 31-30905-AM, 31-30920-AM, 31-30956-AM, RP9-112, ABPN83308011, ABPN83308051, ABPN83308081, ABPN83308181, ABPN83329005, 68183000084, 6818300084, 6818330064, A0681830000, A2218591000, A64403000, BOA7032100409, BOA8032100063, BOA8032100069, BOA8032100149, RDHRD568680, SI0329015, SI0329412, SI0329440, 1280331C1, 1669337C1, 1676649C1, 1676665C91, 431606R1, SR2000016, 125714, PTAC1600, ABPN83-308011, EA1210, RD4157-0, 4379-RD5-6868-0, 4379-RD4157-0, RD5-7125-0, ABP-N83-308011, ABP/N83-308011, RDHRD41570, 93-141, 101107, C80Z19849A, D3ZZ19849A, D2ZZ19849A, E1HZ19849A, N83308041, SIO329440, 134684073, 14100832, D29535350, 430057104, 4379RD41570, 4379RD568680, 7979404098, 71373127, D45092100, 207338, TEM207338, 9705763, 040138123, 040138129, 1804275, 540035, 329406, 600125011, 600124401, RD-5-6868-1P, 11716447
