Description: Block type Expansion Valve 329-403; RD-5-7015-0M, 329-413, ABPN83-308071
Rating: 2 ton
Mount Type: Block Type
Mounting Type: Block
Product Name: Expansion Valve
Refrigerant Type: R12/R134a
Hose Inlet Size: #6
Hose Outlet Size: #10
Evaporator Inlet Size: #8
Evaporator Outlet Size: #10
Notes: O-ring style
Liquid Inlet from Cond: #6 – 3/8”
Liquid Outlet to Evap: #8 – 1/2”
Suction Inlet from Evap: #10 – 5/8”
Suction Outlet to Comp: #10 – 5/8”
Note: A22-45432-000, BOA80-321-00-129, 7787-869221, 4379-RD5-5382-0, 4379-RD570150, 4379-RD5-7015-1,4379-RD553820, EA1315, RD5-9513-0, RD5-7015-0, 1990756-C1, 98370-C3, 1990756-C2, 3501-10001
Applications:
Freightliner Truck Expansion Valves and Orifice Tube Business Class; Classic Series (2002-1994); Columbia, Century Class (2000-1996); CWFC / WFT Series; Classic Series (1996-1989)
MACK Expansion Valve CH,CHN Series (2005-1988); CH,CL Series (1995-1988); Vision (2012-2002); CX, Vision All Series (2001-2000); Granite Series (2007-2002); MH Series (1993-1986)
Peterbilt Expansion Valve (2007-1997)
Western Star Expansion Valve All Models (2016-1993)
John Deere/AGCO – Allis Expansion Valve All Models
CASE / IH – Expansion Valve 3220, 3230, 4210, 4230, 4240, 5120, 5130, 5140, 5220, 5230, 5240, 7110, 7120,7130,7140,7150,7210,7220, 7230, 7240, 7250, 8910, 8920, 8930, 8940, 8950, 9210, 9230, 9240, 9250, 9260, 9270, 9280, 9310, 9330, 9350, 9370, 9380 series
KOMATSU Excavator Expansion Valve
Application: LINKBELT – Excavators 4300,5800,6000 Expansion Valve
Cross Reference: 2001002, EXP-001, AG714552, 1602, 1602G, ABP N83 308031, ABP N83 308041, ABP N83 308071, ABP N83 308101, 329-477, 903-705, 1000039682, 540021, 540128, 540174, 540275, 540276, 540317, 540320, 540345, 00063509, 20-210019, 1990756-C1, 98370-C3, EA1075, EA13150, 932118, 932131, 450-6501, 520-1030, 04-15004-1, E-805026, E-805054, E-805058, E-805602, 932073, 932118, ZGG13615, 329-413, 38614, 38880, 38890, A22-45432-000, BOA80 321 00 129, BOA80 821 00 129, AH122867, AH137702, PTAC1602, 1899005, 1899006, 1899028, 404296, 4379-RD553820, 4379-RD570150, 3902334M91, 1-3615, 1-4700, 1-6289, 1-9058, 207353, 207394, 31-30906, 31-30927-AM, 040138-102, 040138-133, 329-403, 71R8321, 71R8325, 71R8330, 71R8360, 71R8380, RD-5-7015-0, RD-5-9513-0, RF5475402355, EXV-1014, 201019, 210019, 12-0618A, 12-2612A, 12-2612G, 16-7001, EX9403C, 176186, 176282, 3949397, 3949881, RD-5-7015-0P, 31-30927-AM, 31-30939-AM, 31-30957-AM, RDH RD5 9513 0, ABPN83308031, ABPN83308041, ABPN83308071, ABPN83308101, BOA8032100129, BOA8082100129, 125715, PTAC1602G, ABPN83-308071, 7787-869221, 4379-RD5-5382-0, 4379-RD5-7015-1, RD5-9513-0, RD5-7015-0, 1268300384, 31-30902-AM, 126-830-02-84, BOA-80-321-00-129, ABPN83308211, 1550889, T39073, 3901517M1, 1990756C2, 759501, 329403, 329413, 39073, 39485, A2245432000, BOA80332100129, 3411290, 161327A, AH122867, 040138133, 1899028, 1899042, 1899064, 4379RD570150, 7787540021, RD570150, 932073, TEM932073, 3130927, 3130927AM, 3130951, 3131061, 3131061AM, 39073, 180022, 71R8321, M230, 122612A, 7787-540021, 93-122, 4379-RD510546-0
